Automation cycle time calculator
Estimate effective seconds per part, hourly output, daily capacity, target margin and systems required from the complete laser workcell cycle.
- Sequential, dual-station and inline modes
- Loading, process, motion and inspection
- Target capacity and system count
- No registration required
Include every step that controls production output
Laser-on time is only one part of an automated cycle. Add handling, motion, fixturing, inspection, delays, changeover and realistic productive time.
Measure from part arrival to production release
Time every action that prevents the next good part from leaving the workcell.
How automation capacity is calculated
The model first determines the governing station cycle, assigns cycle and setup time to each part, then applies the productive-time allowance.
load + process + motion + fixture + inspection + delayUse when every step waits for the previous step in one station.
max(load, complete machine sequence)Use when one fixture is loaded while the other fixture is being processed.
max(each parallel station step)Use when separate line stations operate simultaneously after the line is full.
(cycle ÷ parts + setup share) ÷ productive timeConverts the ideal station cycle into a practical production estimate.
Reduce cycle time by changing how steps overlap
Parallel operation can improve output, but only when fixtures, safety, controls and operator flow support it.
Sequential workcell
Simple to understand and validate. Every loading, motion, process and inspection step adds directly to the station cycle.
Best for lower volume or compact cellsOverlapped loading
A rotary table or two-position fixture allows loading to occur while the laser processes the other side.
Best when handling limits outputParallel production steps
Dedicated stations operate together, so line rate is controlled by the slowest repeatable station after ramp-up.
Best for stable high-volume flowImprove the step that controls the next good part
Faster robot motion will not improve output when loading, laser processing or inspection remains the governing step.
Loading controls the cycle
Review fixture access, clamps, trays, orientation, operator reach and whether loading can overlap laser operation.
- Use repeatable quick-load nests
- Prepare parts outside the guarded cycle
- Compare dual-station indexing
Laser-on time controls output
Review the approved power, path, passes, speed, optics and whether multiple parts can be processed per fixture.
- Protect required quality first
- Remove unnecessary path travel
- Validate higher-power alternatives
Verification controls release
Optimize camera exposure, database response, code grading, reject logic and communication with the production line.
- Preload valid recipe data
- Improve lighting and trigger position
- Separate inspection where practical
Build the estimate from a representative timed cycle
Use stable production observations instead of the fastest demonstration cycle.
Use an approved laser result
Time the settings that meet the real cleaning, weld or marking requirement on representative parts.
Include normal handling
Measure part pickup, orientation, clamping, confirmation, release and placement into the next process.
Observe acceleration and settling
Robot and axis specifications do not include every path transition, settle delay and process trigger.
Measure productive time
Use actual shift data for replenishment, checks, minor faults, cleaning, breaks and changeover.
Verify the cycle before approving the workcell
Share the part, process result, loading sequence and daily target. Oceanplayer can combine process testing with a practical automation concept.
Validate the process
Confirm quality and laser-on time on representative production parts.
Simulate the sequence
Review reach, fixtures, loading, safety states and process support.
Run a timed trial
Measure repeatable cycles, recovery behavior and output margin.
Continue planning your laser automation project
Select the architecture, validate the process and compare project economics.
