描述
Key Features & Benefits
-
High-Power 2000W Continuous Wave (CW) Technology: Unlike pulsed lasers, our 2000W CW source delivers a high-energy, continuous beam designed for high-efficiency macro cleaning. It dramatically reduces cleaning time on heavy rust layers, thick oxide scales, and stubborn paint on large metal structures like ship hulls, bridges, and machinery parts.
-
Industrial Water-Cooling for 24/7 Operation: Equipped with a built-in high-capacity industrial chiller, this system effectively dissipates heat during high-power output. This allows for continuous, long-duration operation without overheating or power attenuation, ensuring consistent performance even in harsh manufacturing environments.
-
Non-Contact & Consumable-Free Cleaning: Eliminate the recurring costs of abrasive media (sand, dry ice) and hazardous chemicals. This laser cleaner works without touching the substrate, preventing mechanical damage while being environmentally friendly. It produces no secondary waste, making it compliant with strict environmental regulations.
-
Long-Distance & Flexible Handheld Cleaning: Featuring a lightweight, ergonomic cleaning gun coupled with an extended optical fiber cable (typically 10m+), this machine offers superior reach. Operators can easily access hard-to-reach areas, vertical surfaces, and complex geometries, providing flexibility that automated gantry systems cannot match.
-
Smart Control System with Red Light Positioning: The intuitive touchscreen interface allows for precise adjustment of laser power, frequency, and scan width. The integrated red light pointer ensures accurate positioning before the laser fires, reducing operator error and ensuring the cleaning is confined exactly to the target area.
Transform Your Industrial Cleaning Process
Stop struggling with labor-intensive grinding or toxic chemical baths. Our 2000W CW Water-Cooled Laser Cleaner is an investment in efficiency, safety, and quality. Whether you are in the automotive, aerospace, marine, or mold industry, this machine provides a rapid ROI by slashing downtime and material costs. We offer full technical training and after-sales support to ensure you get the most out of your equipment.
Ready to upgrade your production line? We provide customized solutions including robotic arm integration and specific voltage configurations.
📊 Technical Specifications
| Parameter | Specification |
| Model | LC-2000W-CW |
| Laser Power | 2000W |
| Laser Source Type | Continuous Wave (CW) Fiber Laser |
| Laser Wavelength | 1080 ± 5 nm |
| Operating Mode | CW / Modulated |
| Power Adjustment Range | 10% – 100% (Continuously Adjustable) |
| Cleaning Width (Scan Width) | 10mm – 160mm (Adjustable) |
| Cleaning Efficiency | 15 – 45 m²/h (Depends on substrate & rust thickness) |
| Fiber Cable Length | Standard 10m (Optional: 15m / 20m) |
| Cooling Method | Industrial Water Cooling (Built-in Chiller) |
| Cooling Media | Deionized Water or Distilled Water |
| Input Voltage | AC 220V ±10%, 1-Phase, 50/60Hz (Optional: 380V 3-Phase) |
| Total Power Consumption | ≈ 7.0 KW – 8.0 KW |
| Working Environment | Temp: 5°C-40°C / Humidity: < 80% (No Condensation) |
| Machine Dimensions | Approx. 1100mm x 700mm x 1150mm (Customizable) |
| Net Weight | Approx. 180kg – 240kg (Varies by chassis design) |
| Cleaning Head Weight | < 0.8 kg (Handheld part, ergonomic design) |
| Supported Languages | English, Spanish, Russian, German, etc. (Customizable) |
📦 Standard Accessories & Packing List
| Item | Quantity | Description |
| Laser Cleaning Host | 1 Set | Integrated with Water Chiller & Laser Source |
| Handheld Cleaning Gun | 1 Pc | Lightweight, with Safety Trigger |
| Protective Lens | 5 Pcs | Free Spare Parts (High Consumption Item) |
| Safety Goggles | 1 Pair | OD6+ Professional Laser Safety Glasses |
| Control Screen | 1 Set | Touch Screen Panel (Integrated) |
| Power Cable | 1 Pc | Industrial Grade (Customer’s Plug Standard) |
| User Manual | 1 Set | English Operation Guide & Video Tutorials |
