Key Features & Benefits
-
High-Efficiency 1200W CW Technology Utilizes a powerful 1200-watt continuous wave fiber laser source to cover large surface areas quickly. It provides a high-energy density beam that vaporizes contaminants instantly, offering a cleaning speed 5-10 times faster than traditional mechanical grinding or pickling methods.
-
Advanced Water-Cooling System Equipped with a high-performance industrial water chiller, this machine ensures effective heat dissipation for the laser source and optical components. This allows for prolonged, continuous operation in high-temperature or harsh industrial environments without the risk of overheating or downtime.
-
Cost-Effective & Eco-Friendly Operation Say goodbye to expensive consumables like dry ice, abrasives, or chemical solvents. This unit requires only electricity to run, resulting in extremely low operating costs. It produces no secondary waste or hazardous pollution, creating a safer and cleaner working environment for operators.
-
Non-Contact Cleaning & High Precision The laser beam removes surface layers without mechanical contact, minimizing wear on the base material compared to abrasive blasting. The handheld gun features an adjustable scan width, allowing for precise cleaning on both flat surfaces and complex, curved geometries.
-
User-Friendly Design & Long Reach Designed for ease of use, the lightweight handheld cleaning head reduces operator fatigue during long shifts. Coupled with an extended fiber optic cable, it provides excellent flexibility to reach difficult areas, high workplaces, or narrow gaps without moving the main unit.
Transform Your Industrial Cleaning Process
Ready to revolutionize your industrial cleaning process? Stop relying on slow manual labor and hazardous chemicals. Our 1200W Water-Cooled Laser Cleaner provides the power and stability needed for professional industrial applications.
Contact us today to discuss your specific material needs. We will provide you with a comprehensive Technical Datasheet, a list of available protective accessories and nozzles, and a competitive factory-direct price quote.
📊 Technical Specifications
| Parameter | Specification |
| Model | LC-1200W-CW |
| Laser Power | 1200W |
| Laser Source Type | Continuous Wave (CW) Fiber Laser |
| Laser Wavelength | 1080 ± 5 nm |
| Operating Mode | CW / Modulated |
| Power Adjustment Range | 10% – 100% (Continuously Adjustable) |
| Cleaning Width (Scan Width) | 10mm – 160mm (Adjustable) |
| Cleaning Efficiency | 15 – 45 m²/h (Depends on substrate & rust thickness) |
| Fiber Cable Length | Standard 10m (Optional: 15m / 20m) |
| Cooling Method | Industrial Water Cooling (Built-in Chiller) |
| Cooling Media | Deionized Water or Distilled Water |
| Input Voltage | AC 220V ±10%, 1-Phase, 50/60Hz (Optional: 380V 3-Phase) |
| Total Power Consumption | ≈ 7.0 KW – 8.0 KW |
| Working Environment | Temp: 5°C-40°C / Humidity: < 80% (No Condensation) |
| Machine Dimensions | Approx. 1100mm x 700mm x 1150mm (Customizable) |
| Net Weight | Approx. 180kg – 240kg (Varies by chassis design) |
| Cleaning Head Weight | < 0.8 kg (Handheld part, ergonomic design) |
| Supported Languages | English, Spanish, Russian, German, etc. (Customizable) |
📦 Standard Accessories & Packing List
| Item | Quantity | Description |
| Laser Cleaning Host | 1 Set | Integrated with Water Chiller & Laser Source |
| Handheld Cleaning Gun | 1 Pc | Lightweight, with Safety Trigger |
| Protective Lens | 5 Pcs | Free Spare Parts (High Consumption Item) |
| Safety Goggles | 1 Pair | OD6+ Professional Laser Safety Glasses |
| Control Screen | 1 Set | Touch Screen Panel (Integrated) |
| Power Cable | 1 Pc | Industrial Grade (Customer’s Plug Standard) |
| User Manual | 1 Set | English Operation Guide & Video Tutorials |
